Add a tap event to CollectionViewCell while passing Cell data

Question

I want to add a tap event to my CollectionViewCell and to pass there my cell with the data it has. How can I achieve this? Should this event be handled by my ViewController or by CollectionViewCell?

My ViewController:

func collectionView(_ collectionView: UICollectionView, cellForItemAt indexPath: IndexPath) -> UICollectionViewCell {
    let cell = collectionView.dequeueReusableCell(withReuseIdentifier: "CollectionViewCell", for: indexPath) as! CollectionViewCell
    cell.imgImage.image = imageArray[indexPath.row]
    cell.url = "xhini"

    return cell
}

My CollectionViewCell:

class CollectionViewCell: UICollectionViewCell {

    @IBOutlet weak var imgImage: UIImageView!
    var url: String = "url"
}

Milan Nosáľ · Accepted Answer · 2018-02-04T20:14:45.820

5

Implement UICollectionViewDelegate and then you can use following method in the ViewController to react to selecting a cell:

func collectionView(_ collectionView: UICollectionView, didSelectItemAt indexPath: IndexPath) {
    let image = imageArray[indexPath.row]
    // do stuff with image, or with other data that you need
}

Don't forget to set the delegate where you set a data source:

collectionView.dataSource = self
// add this line:
collectionView.delegate = self

UPDATE

Or if you are using a storyboards, you want to set it using storyboards the same way as you set a dataSource for the dataSource of the tableView:

UPDATE 2

Your tap gesture recognizer cancels event for the collection view, so to deal with this, just uncomment the line tap.cancelsTouchesInView = false, and it will work:

    //Looks for single or multiple taps.
    let tap: UITapGestureRecognizer = UITapGestureRecognizer(target: self, action: #selector(ViewController.dismissKeyboard))
    //Uncomment the line below if you want the tap not not interfere and cancel other interactions.
    tap.cancelsTouchesInView = false
    view.addGestureRecognizer(tap)

edited Feb 04 '18 at 20:14

answered Feb 04 '18 at 19:34

Milan Nosáľ

19,169
4
55
90

I add a simple print statement and it does nothing. You mean I should attach here a tap event or smth? – M1X Feb 04 '18 at 19:37
1

@rexhin dont forget to set the delegate to self: `collectionView.delegate = self` – Milan Nosáľ Feb 04 '18 at 19:38
where should I add this line? inside my `func collectionView(_ collectionView: UICollectionView, didSelectItemAt indexPath: IndexPath) { let image = imageArray[indexPath.row] // do stuff with image, or with other data that you need }` – M1X Feb 04 '18 at 19:45
1

@rexhin no, not at all. I think `viewDidLoad` is the best place.. find where you set the data source (where you have line `collectionView.dataSource = self`), and add it there – Milan Nosáľ Feb 04 '18 at 19:47
1

@rexhin : I suggest you go through Apple docs or perhaps a good UICollectionView tutorial or for that matter, tutorial on delegates as to how they are used and where to set them. – Nitish Feb 04 '18 at 19:48
I do not have that line. I do not have a `collectionView` instance at all. I have just an array of UIImages. if you want to check my full project you can check it here: https://gitlab.com/rexhin/ios-kida.git @MilanNosáľ – M1X Feb 04 '18 at 19:50
1

@rexhin add it to `viewDidLoad`, or add the delegate through the storyboard by linking the `delegate` of the collection view to the `viewController` (the same way you did with dataSource) - I'll update the answer to include a screenshot – Milan Nosáľ Feb 04 '18 at 19:54
1

@rexhin : As per the code you have shared there is no UICollectionView. I only guess I can make is that you have directly bind the collectionView from storyboard without creating IBOutlet for that. So there are two ways : 1. Set delegate and dataSource from storyboard. 2. Assign IBOutlet to UICollectionView and link it to storyboard and then set delegate and dataSource as Milan has suggested – Nitish Feb 04 '18 at 19:54
1

@rexhin I updated the question, just link it using storyboards – Milan Nosáľ Feb 04 '18 at 19:56
I have something like that but I do not have an instance for that on my file. something like `collectionView`. I updated my question with an image of what i currently have @Nitish @Milan – M1X Feb 04 '18 at 19:59
1

@rexhin it seems that the delegate is linked.. still not getting that "tap" text printed? – Milan Nosáľ Feb 04 '18 at 20:00
nope, i have a print there but i get nothing, `func collectionView(_ collectionView: UICollectionView, didSelectItemAt indexPath: IndexPath) { print("tap") }` – M1X Feb 04 '18 at 20:03
@rexhin : Found out the issue. Check my answer – Nitish Feb 04 '18 at 20:12
1

Thanks a lot. that was funny. the line was already there but commented out – M1X Feb 04 '18 at 20:18

score 1 · Answer 2 · answered Feb 04 '18 at 20:11

1

I saw your code which you shared in the above answer by @Milan and figured out the reason.
You have added a tap gesture on viewDidLoad of ViewController :

let tap: UITapGestureRecognizer = UITapGestureRecognizer(target: self, action: #selector(ViewController.dismissKeyboard))
view.addGestureRecognizer(tap)

This makes the UICollectionView's didSelectItemAt not getting called.
So comment this code and it should work.
For this gesture, you have to find another approach

answered Feb 04 '18 at 20:11

Nitish

13,845
28
135
263

1

you recommend him to break other functionality to fix his current issue.. how does this help? – Milan Nosáľ Feb 04 '18 at 20:15
Thank you but I have to accept @MilanNosáľ answer because of this reason. :) – M1X Feb 04 '18 at 20:17
1

If you want to get awarded the accepted answer, you can have it. I solved OP's question. Regarding gesture, I would be happy to help if he faces the issue. BTW, it should be OP who should be worried :) – Nitish Feb 04 '18 at 20:18
1

@rexhin : Not a problem. Milan's answer was absolutely correct from implementation point of view and should be awarded. Glad I could help. – Nitish Feb 04 '18 at 20:20
Those lines you told me to remove are used to close the keyboard. If the user clicks everywhere else except the keyboard the keyboard is closed. – M1X Feb 04 '18 at 20:20
1

@rexhin : This should help you. Check the accepted answer : https://stackoverflow.com/questions/40365971/how-to-add-tap-gesture-to-uicollectionview-while-maintaining-cell-selection – Nitish Feb 04 '18 at 20:23
1

Yes, I had that line there before asking this question but for some reason it was commented out – M1X Feb 04 '18 at 20:24
